Solids Handling End Suction Pumps
Pioneer standard centrifugal pumps are designed to handle the toughest dewatering, sewage, and trash applications. Put them to work on wastewater and process flow installations. The overall design makes them ideal for a variety of operating conditions, including municipal wastewater treatment, industrial setting and food processing.
Brand
Overview
Features & Benefits
- Excellent NPSHr provides greater lift capacity
- The 17-4 PH stainless steel shaft is rugged and durable, reducing maintenance costs
- High-efficiency design results in lower fuel costs
- Large Solids handling allows for application flexibility
Specifications
Solids Handling Pump Ends Family Curve
Solids Handling High Head Family Curve
Order Information
44S8B
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 44S8B4T738250T | 4 " | 4 " | 8.25 " / 210 mm | Pioneer Prime | SAE 4 | Ductile Iron |
| 44S8BHC708250T | 4 | 4 " | 8.25 " / 210 mm | None | None | Ductile Iron |
| 44S8BHT708250T | 4 " | 4 " | 8.25 " / 210 mm | Pioneer Prime | None | Ductile Iron |
44S8
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 44S8BHT708250T | 4 " | 4 " | 8.25 " / 210 mm | Pioneer Prime | None | Ductile Iron |
| 44S8HC708250T | 4 " | 4 " | 8.25 " / 210 mm | None | None | Ductile Iron |
| 44S8HT708250T | 4 " | 4 " | 8.25 " / 210 mm | Pioneer Prime | None | Ductile Iron |
44S10
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 44S104T241000T | 4 " | 4 " | 10 " / 254 mm | Pioneer Prime | SAE 4 | CD4MCu Stainless Steel |
| 44S104T741000T | 4 " | 4 " | 10 " / 254 mm | Pioneer Prime | SAE 4 | Ductile Iron |
| 44S10HC201000T | 4 | 4 | 10 " / 254 mm | None | None | CD4MCu Stainless Steel |
| 44S10HC701000T | 4 " | 4 " | 10 " / 254 mm | None | None | Ductile Iron |
| 44S10HT201000T | 4 " | 4 " | 10 " / 254 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 44S10HT701000T | 4 " | 4 " | 10 " / 254 mm | Pioneer Prime | None | Ductile Iron |
64S12
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 64S124T241200T | 6 " | 4 " | 12 " / 305 mm | Pioneer Prime | SAE 4 | CD4MCu Stainless Steel |
| 64S124T741200T | 6 " | 4 " | 12 " / 305 mm | Pioneer Prime | SAE 4 | Ductile Iron |
| 64S12HC201200T | 6 " | 4 " | 12 " / 305 mm | None | None | CD4MCu Stainless Steel |
| 64S12HC701200T | 6 " | 4 " | 12 " / 305 mm | None | None | Ductile Iron |
| 64S12HT201200T | 6 " | 4 " | 12 " / 305 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 64S12HT701200T | 6 " | 4 " | 12 " / 305 mm | Pioneer Prime | None | Ductile Iron |
64S17
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 64S173T251700T | 6 " | 4 " | 17 " / 432 mm | Pioneer Prime | SAE 3 | CD4MCu Stainless Steel |
| 64S173T751700T | 6 " | 4 " | 17 " / 432 mm | Pioneer Prime | SAE 3 | Ductile Iron |
| 64S17HC201700T | 6 " | 4 " | 17 " / 432 mm | None | None | CD4MCu Stainless Steel |
| 64S17HC701700T | 6 " | 4 " | 17 " / 432 mm | None | None | Ductile Iron |
| 64S17HT201700T | 6 " | 4 " | 17 " / 432 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 64S17HT701700T | 6 " | 4 " | 17 " / 432 mm | Pioneer Prime | None | Ductile Iron |
66S10
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 66S104T741000T | 6 " | 6 " | 10 " / 254 mm | Pioneer Prime | SAE 4 | Ductile Iron |
| 66S10HC701000T | 6 " | 6 " | 10 " / 254 mm | None | None | Ductile Iron |
| 66S10HT701000T | 6 " | 6 " | 10 " / 254 mm | Pioneer Prime | None | Ductile Iron |
66S12
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 66S124T241100T | 6 " | 6 " | 11 " / 279 mm | Pioneer Prime | SAE 4 | CD4MCu Stainless Steel |
| 66S124T241200T | 6 " | 6 " | 12 " / 305 mm | Pioneer Prime | SAE 4 | CD4MCu Stainless Steel |
| 66S124T741100T | 6 " | 6 " | 11 " / 279 mm | Pioneer Prime | SAE 4 | Ductile Iron |
| 66S124T741200T | 6 " | 6 " | 12 " / 305 mm | Pioneer Prime | SAE 4 | Ductile Iron |
| 66S12HC201100T | 6 " | 6 " | 11 " / 279 mm | None | None | CD4MCu Stainless Steel |
| 66S12HC201200T | 6 " | 4 " | 12 " / 305 mm | None | None | CD4MCu Stainless Steel |
| 66S12HC701100T | 6 " | 6 " | 11 " / 279 mm | None | None | Ductile Iron |
| 66S12HC701200T | 6 " | 6 " | 12 " / 305 mm | None | None | Ductile Iron |
| 66S12HT201100T | 6 " | 6 " | 11 " / 279 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 66S12HT201200T | 6 " | 6 " | 12 " / 305 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 66S12HT701100T | 6 " | 6 " | 11 " / 279 mm | Pioneer Prime | None | Ductile Iron |
| 66S12HT701200T | 6 " | 6 " | 12 " / 305 mm | Pioneer Prime | None | Ductile Iron |
66S14
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 66S143T251400T | 6 " | 4 " | 14 " / 356 mm | Pioneer Prime | SAE 3 | CD4MCu Stainless Steel |
| 66S143T751400T | 6 " | 6 " | 14 " / 356 mm | Pioneer Prime | SAE 3 | Ductile Iron |
| 66S14HC201400T | 6 " | 6 " | 14 " / 356 mm | None | None | CD4MCu Stainless Steel |
| 66S14HC701400T | 6 " | 6 " | 14 " / 356 mm | None | None | Ductile Iron |
| 66S14HT201400T | 6 " | 6 " | 14 " / 356 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 66S14HT701400T | 6 " | 6 " | 14 " / 356 mm | Pioneer Prime | None | Ductile Iron |
86S17
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 86S171T261700T | 8 " | 6 " | 17 " / 432 mm | Pioneer Prime | SAE 1 | CD4MCu Stainless Steel |
| 86S171T761700T | 8 " | 6 " | 17 " / 432 mm | Pioneer Prime | SAE 1 | Ductile Iron |
| 86S17HC201700T | 8 " | 6 " | 17 " / 432 mm | None | None | CD4MCu Stainless Steel |
| 86S17HC701700T | 8 " | 6 " | 17 " / 432 mm | None | None | Ductile Iron |
| 86S17HT201700T | 8 " | 6 " | 17 " / 432 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 86S17HT701700T | 8 " | 6 " | 17 " / 432 mm | Pioneer Prime | None | Ductile Iron |
86S20
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 86S201T262000T | 8 " | 6 " | 20 " / 508 mm | Pioneer Prime | SAE 1 | CD4MCu Stainless Steel |
| 86S201T762000T | 8 " | 6 " | 20 " / 508 mm | Pioneer Prime | SAE 1 | Ductile Iron |
| 86S20HC202000T | 8 " | 6 " | 20 " / 508 mm | None | None | CD4MCu Stainless Steel |
| 86S20HC702000T | 8 " | 6 " | 20 " / 508 mm | None | None | Ductile Iron |
| 86S20HT202000T | 8 " | 6 " | 20 " / 508 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 86S20HT702000T | 8 " | 6 " | 20 " / 508 mm | Pioneer Prime | None | Ductile Iron |
88S12
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 88S123T251225T | 8 " | 8 " | 12 " / 311 mm | Pioneer Prime | SAE 3 | CD4MCu Stainless Steel |
| 88S123T751225T | 8 " | 8 " | 12 " / 311 mm | None | SAE 3 | Ductile Iron |
| 88S12HC201225T | 8 " | 8 " | 12 " / 311 mm | None | None | CD4MCu Stainless Steel |
| 88S12HC701225T | 8 " | 8 " | 12.25 " / 3151 mm | None | None | Ductile Iron |
| 88S12HT201225T | 8 " | 8 " | 12.25 " / 311 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 88S12HT701225T | 8 " | 8 " | 12.25 " / 311 mm | Pioneer Prime | None | Ductile Iron |
108S17
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 108S171T261750T | 8 " | 10 " | 17 " / 445 mm | Pioneer Prime | SAE 1 | CD4MCu Stainless Steel |
| 108S171T761750T | 10 " | 8 " | 17 " / 445 mm | Pioneer Prime | SAE 1 | Ductile Iron |
| 108S17HC201750T | 10 " | 8 " | 17 " / 445 mm | None | None | CD4MCu Stainless Steel |
| 108S17HC701750T | 10 " | 8 " | 17 " / 445 mm | None | None | Ductile Iron |
| 108S17HT201750T | 10 " | 8 " | 17 " / 445 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 108S17HT701750T | 10 " | 8 " | 17.5 " / 445 mm | Pioneer Prime | None | Ductile Iron |
128S20
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 128S201T761925T | 12 " | 8 " | 19.25 " / 489 mm | Pioneer Prime | SAE 1 | Ductile Iron |
| 128S20HC701925T | 12 " | 8 " | 19.25 " / 489 mm | None | None | Ductile Iron |
| 128S20HT701925T | 12 " | 8 " | 19 " / 489 mm | Pioneer Prime | None | Ductile Iron |
128S22
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 128S221T262200T | 12 " | 8 " | 22" / 559 mm | Pioneer Prime | SAE 1 | CD4MCu Stainless Steel |
| 128S221T762200T | 12 " | 8 " | 22 " / 559 mm | Pioneer Prime | SAE 1 | Ductile Iron |
| 128S22HC202200T | 12 " | 8 " | 22 " / 559 mm | None | None | CD4MCu Stainless Steel |
| 128S22HC702200T | 12 " | 8 " | 22 " / 559 mm | None | None | Ductile Iron |
| 128S22HT202200T | 12 " | 8 " | 22 " / 559 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
| 128S22HT702200T | 12 " | 8 " | 22 " / 559 mm | Pioneer Prime | None | Ductile Iron |
1212S17
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 1212S171T761725T | 12 " | 12 " | 17 " / 438 mm | Pioneer Prime | SAE 1 | Ductile Iron |
| 1212S17HC701725T | 12 " | 12 " | 17 " / 438 mm | None | None | Ductile Iron |
| 1212S17HT701725T | 12 " | 12 " | 17.25 " / 438 mm | Pioneer Prime | None | Ductile Iron |
1414S17
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| PPHF1414S17-005 | 14 " | 14 " | 17.5 " / 445 mm | Pioneer Prime | None | Ductile Iron |
| SCHF1414S17-000 | 14 " | 14 " | 17.5 " / 445 mm | None | None | Ductile Iron |
1818S22
| Item | Suction | Discharge | Impeller Dia. | Priming Type | SAE Size | Volute Material |
|---|---|---|---|---|---|---|
| 1818S22-0005 | 18 " | 18 " | 22.5 " / 572 mm | Pioneer Prime | None | Ductile Iron |
| 1818S22-0007 | 18 " | 18 " | 22.5 " / 572 mm | None | None | Ductile Iron |
| PPHF1818S22-010 | 18 " | 18 " | 22.5 " / 572 mm | Pioneer Prime | None | CD4MCu Stainless Steel |
Support Materials
Brochures
Manuals
Curves
Parts & Accessories
Solids Handling Parts & Accessories
108S17 Rotating Assembly is a pre-assembled shaft including full bearing housing, pre-installed bearings, cassette seals, mechanical seal, impeller, backplate and bracket.
1212S17 Rotating Assembly is a pre-assembled shaft including full bearing housing, pre-installed bearings, cassette seals, mechanical seal, impeller, backplate and bracket.
128S22 Rotating Assembly is a pre-assembled shaft including full bearing housing, pre-installed bearings, cassette seals, mechanical seal, impeller, backplate and bracket.
64S17, 86S17 Rotating Assembly is a pre-assembled shaft including full bearing housing, pre-installed bearings, cassette seals, mechanical seal, impeller, backplate and bracket.
66S12, 66S14, 88S12 Rotating Assembly is a pre-assembled shaft including full bearing housing, pre-installed bearings, cassette seals, mechanical seal, impeller, backplate and bracket.
88S12 Rotating Assembly is a pre-assembled shaft including full bearing housing, pre-installed bearings, cassette seals, mechanical seal, impeller, backplate and bracket.
Mechanical seal kit for 66S12, 66S14, 88S12. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 66S10. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 44S8, 44S8B. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 44S10. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 108S17. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 64S17, 86S17. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 108C24, 128S20, 128S22. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 86S20. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 1818S22. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 1818S22. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 1212S17. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Bearing frame kit for 66S12, 66S14, 88S12. Contains bearings
Bearing frame kit for 44S10. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Bearing frame kit for 66S10. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Bearing frame kit for 108S17. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Bearing frame kit for 64S17, 86S17. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Bearing frame kit for 86S20. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Bearing frame kit for 1818S22. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Bearing frame kit for 1212S17. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Pump shaft with pre-installed factory outboard and inboard bearings. Standard 17-4 PH stainless steel shaft. For pump model(s): 86S17.
Pump shaft with pre-installed factory outboard and inboard bearings. Standard 17-4 PH stainless steel shaft. For pump model(s): 66S12, 66S14, 88S12.
Pump shaft with pre-installed factory outboard and inboard bearings. Standard 17-4 PH stainless steel shaft. For pump model(s): 44S10.
Pump shaft with pre-installed factory outboard and inboard bearings. Standard 17-4 PH stainless steel shaft. For pump model(s): 108S17, 1212S17.
Pump shaft with pre-installed factory outboard and inboard bearings. Standard 17-4 PH stainless steel shaft. For pump model(s): 44S8, 44S8B, 66S10.
Kit including impeller screw, impeller washer, lock washer and tong washer. For pump model(s): 44S10
Kit including impeller screw, impeller washer, lock washer and tong washer. For pump model(s): 44S8, 44S8B, 66S10
Kit including impeller screw, impeller washer, lock washer and tong washer. For pump model(s): 64S17, 86S17
Kit including impeller screw, impeller washer, lock washer and tong washer. For pump model(s): 108S17, 1212S17, 1414S17, 1818S22
Kit including all o-rings required to service the pump. For pump model(s): 44S10, 64S12.
Kit including all o-rings required to service the pump. For pump model(s): 66S12, 66S14, 88S12.
Kit including all o-rings required to service the pump. For pump model(s): 108S17, 1212S17, 1414S17.
Bearing frame kit for 108C24, 128S20. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Pump shaft with pre-installed factory outboard and inboard bearings. Standard 17-4 PH stainless steel shaft. For pump model(s): 128S20, 108C24.
Kit including all o-rings required to service the pump. For pump model(s): 86S20, 128S20, 128S22, 108C24.
Kit including all o-rings required to service the pump. For pump model(s): 63C17, 64C17, 86C17, 86C17B, 43C21, 64C21, 86C21, 64S17, 86S17, 108C18.
Pump shaft with pre-installed factory outboard and inboard bearings. Standard 17-4 PH stainless steel shaft. For pump model(s): 66S12, 66S14, 88S12, 64S12, 86C14, 66C14, 64C17, 63C17, 64C14, 53C14, 64C21, 43C21, 86C17B, 86C17, 108C18, 1010C14.
Kit including all o-rings required to service the pump. For pump model(s): 315C75, 32C75, 425C75, 43C75, 44C75, 54C75, 32C10, 425C10, 43C10, 64C10, 66S10, 86C10, 44S8, 44S8B, 86C95.
Mechanical seal kit for 1414S17. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Mechanical seal kit for 64S12. Includes the mechanical seal, cassette seal, impeller key and shims, and a lock washer kit.
Bearing frame kit for 44S8, 44S8B. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Bearing frame kit for 1414S17. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Bearing frame kit for 64S12. Contains all necessary bearings, snap ring, cassette seal, shims, and o-rings to perform a bearing replacement
Related Products
Ready to working with us?
Please fill in the following form. You will be contacted as soon as possible.
